Description

Assortment of analog and digital stuff for TT06

README

Setup

Make sure the $PDK_ROOT & $PDK environment variables are setup.

You will need a recent version of Magic and Netgen:

• https://github.com/RTimothyEdwards/magic
• https://github.com/RTimothyEdwards/netgen

Update files for your project name

• update mag/Makefile to set your project name at the top of the file
• update src/project.v to match your project name

Initialise the project

Run:

make start

This sets up a .mag file ready to start working. It includes all the pins for Tiny Tapeout and 2 power lines.

The default is to use a 1x2 block (the smallest). If you need more space - check here.

Work on the project

make magic

Run LVS

Update src/project.v to add the cells you've used. This Verilog can be treated as blackbox, gatelevel Verilog. So the blackboxed cells don't need to exist, but if you want LVS to check your wiring, then the names and wires should all match your intended layout.

If your design includes custom analog blocks, then you can also add their spice netlists to the mag/tcl/lvs_netgen.tcl.

Then run:

make lvs

Run DRC

It's best to be checking DRC as you are drawing your layout. You can check from the commandline like this:

make drc

Update the GDS and LEF

Once your layout is ready to submit generate the GDS and LEF:

make update_gds

Then head to https://app.tinytapeout.com to submit your design onto the next shuttle.
