README

ConeRGB Underglow3 Nerves Support

Hex version

This is the base Nerves System configuration for ConeRGB V3.

FeatureDescription
CPU1.2 GHz ARM Cortex-A7 Dual-Core
Memory128 MB DDR3
StorageMicroSD
Linux kernel6.1 w/ patches
IEx terminalUART ttyS0
GPIO, I2C, SPIYes - Elixir Circuits
DisplayNo
ADCNo
PWM8 channels
UARTttyS0
CameraNo
EthernetNo
WiFiOnboard WiFi
RTCNo
HW WatchdogYes

Special Thanks

Most of the hard work in this repo was gleamed from YuzukiSBC
