README

LED-Window-Matrix Neo

Complete new version of our last semester's project.

New Features

  • Complete rewrite of the mesh using ESP-MDF
  • UDP based bridge for easy and fast communication
  • Updated PixelBridge
  • (Planned) Management Software for End User

Old Media

https://user-images.githubusercontent.com/36489816/166237971-5a803816-1b47-4246-80e3-ec737a2a25ef.mp4
