GPS-based local relative navigation system for group of up to 6 members

README

Eleph Hardware

This folder contains hardware design of the ELEPH

Design files

In the "KiCad" folder you can find KiCad project of the Eleph.

Schematic

In the "Schematic" folder you can find PDF file with the schematic diagram.

Production files

In the "Gerbers" folder you can find production files of Eleph.

Hardware Notes

Couple of words about power supply. Supply chain is Single 18650 -> LDO 3.3V. I found no reason to put DC/DC because in common they have 80%-90% of efficiency, while LDO has ~78% in worst case (3.3V / 4.2V = 0.78). Do the increased complexity and cost worth several percent of efficiency? I do not think so.
