Description

Hardware design for modular CNC controller

README

rioctrl-spindle

This module provides:

• 2 analog outputs (0..10V)
• RS-485 interface for Modbus
• RS-422 interface (for full-duplex serial communication, pending software support)
• Differential encoder interface

Only analog outputs and Modbus has been tested!

Pinout

AIN0	GND
AIN1	SER_TX_A
MODBUS_A	SER_TX_B
MODBUS_B	SER_RX_A
x	SER_RX_B

Changelog

v1.0

Initial released version.
