Description

A test project for the video tutorial using KDT_Hierarchical_KiBot template

README

---

---

SPECIFICATIONS

Parameter	Value
Dimensions	${bb_w_mm} × ${bb_h_mm} mm

---

DIRECTORY STRUCTURE

.
├─ Computations       # Misc calculations
├─ HTML               # HTML files for generated webpage
├─ Images             # Pictures and renders
│
├─ kibot_resources    # External resources for KiBot
│  ├─ colors          # Color theme for KiCad
│  ├─ fonts           # Fonts used in the project
│  ├─ scripts         # External scripts used with KiBot
│  └─ templates       # Templates for KiBot generated reports
│
├─ kibot_yaml         # KiBot YAML config files
├─ KiRI               # KiRI (PCB diff viewer) files
│
├─ lib                # KiCad footprint and symbol libraries
│  ├─ 3d_models       # Component 3D models
│  ├─ lib_fp          # Footprint libraries
│  └─ lib_sym         # Symbol libraries
│
├─ Logos              # Logos
│
├─ Manufacturing      # Assembly and fabrication documents
│  ├─ Assembly        # Assembly documents (BoM, pos, notes)
│  │
│  └─ Fabrication     # Fabrication documents (ZIP, notes)
│     ├─ Drill Tables # CSV drill tables
│     └─ Gerbers      # Gerbers
│
├─ Report             # Reports for ERC/DRC
├─ Schematic          # PDF of schematic
├─ Templates          # Title block templates
├─ Testing
│  └─ Testpoints      # Testpoints tables
│
└─ Variants           # Outputs for assembly variants
