README

hw-spimux

PMOD Quad SPI flash mux debug board Breaks out the Gimletlet QSPI port to a MT25QU256ABA8E12 Flash memory IC.

Model Change Notices

We use Model Change Notices (MCNs) to track rework made in between CAD updates andboard spins. These are preserved in this repo for historical and reference reasons even after the CAD has been updated.

Status

The CAD represents what was built without the MCN(s) applied.
