Drop-in replacement Bird Brain design for Bird 3 scooters.

README

[!NOTE] This design has been assembled and is working with no errata discovered yet.

Development

This was developed in KiCad 8, a FOSS EDA suite. Most or all of the symbols, footprints, and 3D models have been included in the repo to reduce the chance of broken references.

Ordering Information

JLCPCB is a good place from which to order a PCB.

• The gerber files are in the ./plots folder.
• The Bill of Materials is at ./BOM.csv.

These JLCPCB settings were used for the order:

Setting	Value
Layers	2
Dimension	43 mm * 108 mm
PCB Thickness	1.6
Impedance Control	no
Material Type	FR4-Standard TG 135-140
Via Covering	Tented
Outer Copper Weight	1 oz
Castellated Holes	no
Edge Plating	no
Remove Order Number	Specify a location
Board Outline Tolerance	±0.2mm(Regular)

Fixes from Rev 2

• TBA

Improvements from Rev 2

• TBA

Errata

• TBA

Bill of Materials

An interactive BOM generated by InteractiveHtmlBOM is available at https://html-preview.github.io/?url=https://github.com/ysoyjcgoxohxoh/Bird3/blob/master/PCB/Bird3Controller_Rev3/bom/ibom.html

PDF Schematic

A PDF schematic is available at Bird3Controller.pdf. When opened in a more advanced viewer such as Acrobat Reader, the components are bookmarked, and both components and nets are clickable as shown in this screenshot, making it easy to open the part's datasheet or Mouser.com listing.

PNG Schematic
